HRL219B8
The HRL219B8 Joystick, part number HRL219B8, is a versatile and high-quality joystick that offers precise control and ease of use. With its actuator, or organ de manoeuvre, the joystick allows for smooth and accurate movement in any direction. The HRL219B8 features a convenient rear mounting design, or montageart, making it easy to install and integrate into your system. Plus, with its built-in backlighting, or rétroéclairage, you can easily use the joystick in low-light environments. The wheel of the joystick comes in a vibrant orange color, adding a touch of style to your setup. The HRL219B8 offers single 05 V to 45 V output options, allowing for compatibility with a wide range of devices and systems.
Key Features
- Output Options: single 05 v to 45 v
- Actuator: Wheel Without Tab
- Mounting: Rear
- Mechanical: Friction Hold with Center Detent
- Wheel Colors: Orange
- Back lighting: Yes
Specifications
Distinctive Features:
- Friction hold - 2 versions: 11 detents along the travel or 1 detentat center
- Single or dual analog outputs
- Backlighting option
- Electronics sealed to IP68
- SIL2 capable
General Specifications:
- Spring to center return
- Backlighting and detent options available
- EMI/RFI shielding
- APEM SAS patented design
- RGB option available
Environmental Specifications:
- Operating Temperature: -30°C to +70°C (-22°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Sealing to IP68 against water and dust
- Shock resistance: 50g during 11ms
- Vibration resistance: 10-500Hz
- Salt spray: IEC 512-6, test 11f
- EMI/RF shielding: 100V/m, complies with IEC 61000- 4-3 and ISO 11452-2
- ESD: Complies with 16KV EN 61000-4-2
Electrical Specifications:
- Sensor type: Hall effect
- Supply voltage: 5VDC ± 0.5V
- Reverse polarity: -10V max
- Overvoltage: +20V max
- Return to center voltage (no load): ±0.2V
- Consumption: 11 mA max (single output), 22mA max (dual output)
- LED supply: 6VDC 10mA
