QRM64BXXSB28E
The QRM64BXXSB28E is an LED indicator with a mounting hole diameter of 6 mm, rear epoxy pins as terminals, a black bezel finish, fixed light illumination, and a super bright blue LED color. It operates at a voltage of 28 VDC and has a sealing rating of IP67.
Key Features
- Mounting hole: Ø6 mm
- Terminals: Pins
- Voltage: 28 VDC
- Sealing: IP67 (Standard)
- Led color: Super Bright Blue
- Type of illumination: Fixed Light
- Bezel finish: Black
Specifications
General Specifications:
- Max Reverse Voltage: 5 V
- Viewing Angle: 60°
- Life Expectancy: 100,000 hours
- Max panel thickness: 3.5 mm
- Torque: 60 cNm
Environmental Specifications:
- Operating Temperature Range: –40 to +85 °C
- Storage Temperature Range: –55 to +100 °C
- IP67 sealed (EN60529)
Electrical Specifications:
- 02 (No Resistor) 1.8 to 3.8 VDC 20 mA max
- 6 VDC 5.4 to 6.6 VDC 20 mA
- 12 VDC 10.8 to 13.2 VDC 20 mA
- 24 VDC 21.6 to 26.4 VDC 20 mA
- 28 VDC 25.2 to 30.8 VDC 20 mA
