HRL206B7
Introducing the HRL206B7 Joystick, a versatile and reliable device designed to enhance your control experience. With its sleek and ergonomic design, this joystick is perfect for a wide range of applications. The actuator, or organe de manoeuvre, allows for smooth and precise movements, ensuring optimal control. The rear mounting option ensures easy installation and stability. Plus, with its no backlighting feature, you can use it in any lighting condition. The vibrant red wheel adds a touch of style and personality to your setup. Choose from a single output option of 05 V to 45 V for seamless integration with your system. And with its friction hold and 11 detents, you can enjoy a tactile and responsive experience. Upgrade your control game with the HRL206B7 Joystick.
Key Features
- Mechanical Functions: Friction hold with 11 detents
- Wheel Colors: Red
- Actuator: Wheel without tab
- Backlighting: No
- Output Options: Single 0.5 V to 4.5 V
- Series: HR
- Mounting Options: Rear
Specifications
Distinctive Features:
- Friction hold - 2 versions: 11 detents along the travel or 1 detentat center
- Single or dual analog outputs
- Backlighting option
- Electronics sealed to IP68
- SIL2 capable
General Specifications:
- Spring to center return
- Backlighting and detent options available
- EMI/RFI shielding
- APEM SAS patented design
- RGB option available
Environmental Specifications:
- Operating Temperature: -30°C to +70°C (-22°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Sealing to IP68 against water and dust
- Shock resistance: 50g during 11ms
- Vibration resistance: 10-500Hz
- Salt spray: IEC 512-6, test 11f
- EMI/RF shielding: 100V/m, complies with IEC 61000- 4-3 and ISO 11452-2
- ESD: Complies with 16KV EN 61000-4-2
Electrical Specifications:
- Sensor type: Hall effect
- Supply voltage: 5VDC ± 0.5V
- Reverse polarity: -10V max
- Overvoltage: +20V max
- Return to center voltage (no load): ±0.2V
- Consumption: 11 mA max (single output), 22mA max (dual output)
- LED supply: 6VDC 10mA
