Solution for your small vehicle
Date: 21/06/2022
Loading...
APEM launches a new panel sealed solution to provide basic functionality to small vehicles that drive on the road. Compact, easy-to-install, and easy-to-use, this solution offers some customization possibilities so you can focus on your core business.
MAIN BENEFITS
Provides the necessary functionality to drive on the road
Cost-effective plug & play solution
Easy to use
MAIN APPLICATIONS
Small tractors
Lawn and garden equipment
Commercial vehicles
Recreational vehicles
Technical Features
4 fixed positions with the rotary control
3 fixed positions with the lever control
1 momentary pushbutton in the center
Front panel Sealing: IP67
Max. current/voltage rating with resistive load:
Pushbutton: 10 A, 12 VDC
Rotary & lever: 15 A, 12VDC
Dielectric withstanding voltage: 500 Vrms
Insulation resistance: 5000 MΩ Minimum for 1min @ 500 VDC
Initial contact resistance: 25 mΩ Max.
Electrical life: 10,000 cycles
Wire conductor cross section:
1.5 mm² for blue wire core
Other wire core is 1.0 mm²
EXPERT’S ADVICE
The purpose of this product is that you can just plug it into your system, and it provides the necessary functionality you need to drive your small vehicle on public roads. It was designed to make your life easier, so don’t hesitate to ask for customizations to fit your specific need.
Vivien Rineau
Product Manager
