Maximize control in minimal space with the new XS + Z axis joystick
Date: 29/09/2026
In industrial control panels, handheld remote controls, and compact machine interfaces, space is limited. Operators need precise control while manufacturers must integrate more functions into smaller footprints. Traditional joysticks often require significant panel depth and height, making integration challenging in compact equipment. Their exposed actuators can also be vulnerable to accidental activation, impacts, or harsh environmental conditions. The new XS series with Z Axis was developed to solve these challenges. Combining an ultra-low-profile design with three-axis functionality, it enables operators to control more functions from a compact interface. Rather than forcing designers to compromise between functionality and space, the XS + Z axis delivers both.
What is the XS series with Z axis?
The XS series with Z axis is a sealed, low-profile joystick designed for applications where space optimization and multi-axis control are the priority.
It combines four key advantages in a single compact device:
Ultra-low-profile design to help prevent accidental activation.
Three-axis control capability for enhanced versatility.
Reliable operation in harsh environments thanks to IP66 sealing.
Compact under-panel depth for seamless integration.
The integrated Z axis adds a third control dimension while maintaining the compact footprint that makes the XS Series ideal for constrained installations.
Download datasheet & CAD files
Key features of this low profile joystick
The low-profile XS+Z axis joystick is designed to deliver reliable performance in demanding environments:
Available in one, two or three-axis configurations
Supports analog or PWM output signals
Ultra low-profile design: less than 43 mm above panel mounting and less than 33 mm below panel mounting (for a 3 mm panel thickness)
IP66-rated sealing above the panel for high resistance to dust and water ingress
Wide operating temperature range: from -30 °C to +85 °C
Extended storage temperature range: from -40 °C to +85 °C
4 key reasons to choose the XS+Z joystick
1. Maximize control while minimizing panel space
The XS Joystick's ultra-compact design allows you to integrate advanced control functions into space-constrained panels without compromising ergonomics or performance.
2. Increase functionality without adding complexity
The integrated Z axis provides an additional control input directly from the joystick, enabling more commands while keeping your operator interface simple, intuitive, and uncluttered.
3. Rely on dependable performance in demanding environments
Designed for harsh industrial and mobile applications, the XS Joystick delivers reliable operation in extreme temperatures and is protected against dust and water ingress with IP66 sealing above the panel.
4. Enhance operator comfort and control
The low-profile actuator, smooth guided movement, and textured grip provide precise, intuitive operation. The Z Axis is easy to activate, even when wearing gloves or working in challenging conditions, helping operators work with greater confidence and accuracy.
Where can you find the XS joystick?
Construction machinery
The sealed and rugged design withstands dust, water, vibration, and outdoor operating conditions. Its compact dimensions allow manufacturers to integrate multiple control points without increasing panel size (belly boxe).
Industrial controls
Perfect for material handling vehicles and mobile equipment where control density and reliability are critical.
Measuring and inspection systems
Provides precise motion control while fitting into compact operator interfaces.
💡Expert's perspective
"With the XS Series featuring Z Axis, our objective was to provide machine designers with a compact joystick capable of delivering advanced functionality without compromising ergonomics or reliability. The ultra-low-profile design reduces accidental activation risks while the third axis expands control possibilities in applications where every millimeter of panel space matters."
Richard Bateman – Product Manager
Want to discover more?
If you are designing industrial remote controls, measuring systems, or construction equipment, the XS + Z axis joystick delivers compact integration, precise control, and reliable performance in demanding environments.
Request a sample, or contact our team to learn more.
